A single chain operates two panels for constant comfort with a measured, silent and balanced movement.

Exclusively for Italy is a new mechanism for quality shading. “One chain, double touch” for rational and elegant control of the light. Technology and style for an efficient and unique system.

APPLICATION: vertical
INSTALLATION: Internal
HEADBOX: in extruded aluminium 31 × 30, available in white or dark brown
ROLLER TUBE: Ø 15 steel shaft with cord winder for lowering.
BACKING: in steel 25 × 12
COLOUR: white
OPERATION: Drive 6 chain in nylon with Ø 4.5 mm PVC beads, equipped with a child safety release device – JA 06 soft motor, 230V/50Hz, torque 6Nm, speed 26 rpm, complete with M/F plug
MOUNTING: wall or ceiling
SIZES: Min. L 40 cm – Max L 400 cm x H 300 cm
Number of stop points based on the width of the blind.

APPLICATION: vertical
INSTALLATION: Internal
HEADBOX: double in extruded aluminium 52 × 42, available in white or dark brown
ROLLER TUBE: double Ø 15 steel shaft with cord winder for lowering.
HEM BAR: two 25 × 12 mm steel hem bars
COLOUR: white
OPERATION: Single drive 6 chain in nylon with Ø 4.5 mm PVC beads equipped with a child safety release device
MOUNTING: wall or ceiling
SIZES: Min. L 45 cm – Max L 400 cm x H 300 cm
Number of stop points based on the width of the blind.
