Application: Vertical
Installation: Internal

With frontal or ceiling mounting, there is the option of a lacquered roller holder profile to facilitate assembly. The system is also suited to other applications, for example: curtains for refrigerated counters, industrial sectors, décor.

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal Minimum width 45 cm
MOUNTING BRACKET: 41 × 50 mm in white or black PVC
ROLLER TUBE: Ø 26 mm in ogive-free extruded aluminium
HEM BAR: FD21 in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, black RAL 9005 in transparent semi-shading and tassel with pull cord
OPERATION: slow-rise spring
MOUNTING: wall or ceiling
SIZES: L min 60 cm Max L 160 x H 200 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal
MOUNTING BRACKET: 52 × 66 mm in painted iron with PVC bracket covers (in white, black, grey); 52 × 80 mm bracket on request. Magnetic bracket covers in satin-finish aluminium (at an additional charge)
ROLLER TUBE: Ø 39 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 2012 Series in extruded aluminium with PVC plugs FR23 hem bar with the perlon cord side channel variant
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: chain with EASY LOCK friction control in PVC complete with cap on the opposite side with retractable pin to facilitate the disassembly of the roller from the brackets. Drive 6 chain in nylon with Ø 4.5 mm PVC beads equipped with a child safety release device pursuant to the UNI EN13120:2014 standard
MOUNTING: wall or ceiling Supplementary pre-assembly profile in painted extruded aluminium (white RAL 9010, matt black RAL 9005, anodised silver)
SIZES: Min. L 60 – Max L 240 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal Minimum width 80 cm
MOUNTING BRACKET: 52 × 66 mm in painted iron with PVC bracket covers (in white, black, grey); 52 × 80 mm bracket on request. Magnetic bracket covers in satin-finish aluminium (at an additional charge)
ROLLER TUBE: Ø 39 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 2012 Series in extruded aluminium with PVC plugs FR23 hem bar with the perlon cord side channel variant
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: chain combined with EASY LOCK friction control in PVC complete with cap on the opposite side with retractable pin to facilitate the disassembly of the roller from the brackets and return spring to facilitate lifting the fabric. Drive 6 chain in nylon with Ø 4.5 mm PVC beads equipped with
child safety release device pursuant to the UNI EN13120:2014 standard.
MOUNTING: wall or ceiling Supplementary pre-assembly profile in painted extruded aluminium (white RAL 9010, matt black RAL 9005, anodised silver)
SIZES: Min. L 80 – Max L 240 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal Minimum width 80 cm
MOUNTING BRACKET: 52 × 66 mm in painted iron with PVC bracket covers (in white, black, grey); 52 × 80 mm bracket on request. Magnetic bracket covers in satin-finish aluminium (at an additional charge)
ROLLER TUBE: Ø 39 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 2012 Series in extruded aluminium with PVC plugs FR23 hem bar with the perlon cord side channel variant
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: chain combined with EASY LOCK friction control in PVC complete with cap on the opposite side with retractable pin to facilitate the disassembly of the roller from the brackets and return spring to facilitate lifting the fabric. Drive 6 chain in nylon with Ø 4.5 mm PVC beads equipped with
child safety release device pursuant to the UNI EN13120:2014 standard.
MOUNTING: wall or ceiling Supplementary pre-assembly profile in painted extruded aluminium (white RAL 9010, matt black RAL 9005, anodised silver)
SIZES: Min. L 80 – Max L 240 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical
Installation: internal Minimum width 80 cm
MOUNTING BRACKET: 82×92 mm in painted iron with PVC bracket covers (white, black, grey).
ROLLER TUBE: Ø 60 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 or FR23 2012 Series in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: chain, PVC friction control unit with compensation spring to facilitate
raising the panel. Chromed brass chain, drive 6, Ø 45 mm beads, equipped with a child safety device in accordance with the UNI EN13120:2014 standard.
MOUNTING: wall or ceiling
SIZES: Min. L 80 – Max L 350 x H 350 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal
MOUNTING BRACKET: 82×92 mm in painted galvanised iron with PVC bracket covers (white, black, grey). Magnetic bracket covers in satin-finish aluminium (at an additional charge) Painted galvanised iron counterplates complete with AISI 304 stainless-steel cord tensioning cylinder for the version with supplementary cables.
ROLLER TUBE: Ø 42-49 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: FR23 in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: zamak winch with a 1:3.3 gear ratio and limit switch. Tubular rod Ø 13 mm in extruded aluminium,
removable with magnetic attachment and PVC rod clip, jointed handle with PVC coated grip.
MOUNTING: wall or ceiling
SIZES:
With roller Ø 42 – Min. L 80 cm – Max L 240 x H 320 cm
With roller Ø 49 – Min. L 250 cm – Max L 320 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal
MOUNTING BRACKET: 82×92 mm in painted iron with PVC bracket covers (white, black, grey). Magnetic bracket covers in satin-finish aluminium (at an additional charge) Painted galvanised iron counterplates complete with AISI 304 stainless-steel cord tensioning cylinder for the version with supplementary cables.
ROLLER TUBE: Ø 60 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: FR23 in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: tubular motor 230V/50Hz, M50, with up/down limit switch and power cable
Heat protection index and splash-proof index IP44. Switch excluded
MOUNTING: wall or ceiling
SIZES: Min. L 80 – Max L 350 x H 350 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal
MOUNTING BRACKET: 110×120 mm in painted galvanised iron with PVC bracket covers (white, black, grey). Supplementary 110×120 mm brackets in AISI 304 stainless steel.
ROLLER TUBE: Ø 78-85 mm in galvanised iron with ogive to facilitate the maintenance of the cloth.
HEM BAR: FR23 in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: zamak winch with a 1:4.7 gear ratio without limit switch. Extruded aluminium tubular rod Ø 13 mm, removable with magnetic attachment and PVC rod clips, jointed handle with PVC coated handle.
MOUNTING: wall or ceiling
SIZES:
Roller Ø 78 Min. L 80 – Max L 390 x H 320 cm
Roller Ø 85 Min. L 80 – Max L 400 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal
MOUNTING BRACKET: 110×120 mm in painted galvanised iron with PVC bracket covers (white, black, grey). Supplementary 110×120 mm brackets in AISI 304 stainless steel.
ROLLER TUBE: Ø 78-85 mm in galvanised iron with ogive to facilitate the maintenance of the cloth.
HEM BAR: FR23 in extruded aluminium with PVC plugs
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: tubular motor 230V/50Hz, M50, with up/down limit switch and power cable
Heat protection index and splash-proof index IP44. Switch excluded
MOUNTING: wall or ceiling
SIZES:
Roller Ø 78 Min. L 80 – Max L 390 x H 320 cm
Roller Ø 85 Min. L 400 – Max L 500 x H 400 cm

CHARACTERISTICS:

APPLICATION: vertical
INSTALLATION: internal Minimum width 80 cm
MOUNTING BRACKET: 52 × 66 mm in painted iron with PVC bracket covers (in white, black, grey); 52 × 80 mm bracket on request. Magnetic bracket covers in satin-finish aluminium (at an additional charge)
ROLLER TUBE: Ø 49 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 2012 Series in extruded aluminium with PVC plugs FR23 hem bar with the perlon cord side channel variant
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: tubular motor 230V/50Hz, M40, with up/down limit switch and power cable
Heat protection index and splash-proof index IP44, switch excluded.
Opposite side cap with retractable pin to facilitate the disassembly of the roller from the brackets.
MOUNTING: wall or ceiling Supplementary pre-assembly profile in painted extruded aluminium (white RAL 9010, matt black RAL 9005, anodised silver)
SIZES: Min. L 80 – Max L 320 x H 320 cm

CHARACTERISTICS:

APPLICATION: vertical, for large dimensions
INSTALLATION: internal Minimum width 80 cm
MOUNTING BRACKET: 52 × 66 mm in painted iron with PVC bracket covers (in white, black, grey); 52 × 80 mm bracket on request. Magnetic bracket covers in satin-finish aluminium (at an additional charge)
ROLLER TUBE: Ø 49 mm in ogive-free extruded aluminium to facilitate maintenance of the fabric
HEM BAR: F21 2012 Series in extruded aluminium with PVC plugs FR23 hem bar with the perlon cord side channel variant
COLOUR: White RAL 9010, ivory RAL 1013, brown RAL 8017, matt black RAL 9005, anodised silver
OPERATION: chain combined with EASY LOCK friction control in PVC complete with cap on the opposite side with retractable pin to facilitate the disassembly of the roller from the brackets and return spring to facilitate lifting the fabric. Drive 6 chain in nylon with Ø 4.5 mm PVC beads equipped with a child safety release device pursuant to the UNI EN13120:2014 standard
MOUNTING: wall or ceiling Supplementary pre-assembly profile in painted extruded aluminium (white RAL 9010, matt black RAL 9005, anodised silver)
SIZES: Min. L 80 – Max L 320 x H 320 cm
